Step 1: Management Server

This step provisions the Azure infrastructure and deploys NetBird’s management server at netbird.gsisg.com.

1.1 Choose Your Azure VM

You have two options: use the existing GSI-AZ-IDM VM (recommended — saves ~$35-51/month) or provision a new dedicated VM.

Option A: Use Existing GSI-AZ-IDM (Recommended)

GSI-AZ-IDM is already running Ubuntu 24.04 with Docker and has more than enough capacity for NetBird alongside its current Prefect workloads.

Setting	Value
VM Name	GSI-AZ-IDM (existing)
Resource Group	rg-idm-webapp-prod
Region	West US 2
Size	B2s v2 (2 vCPU, 8 GiB RAM) — double the recommended minimum
Public IP	4.154.241.58 (already assigned)
Private IP	10.50.0.16
VNet	GSI-AZ-NET / GSI-AZ-SUB01
Additional cost	$0/month — already paid for

NetBird’s management server uses ~1 CPU and ~2 GB RAM for signaling only (no data-plane traffic). With 8 GB RAM, there is ample headroom for both Prefect and NetBird.

To proceed with this option: Skip to 1.2 Configure the NSG and add the required ports to GSI-AZ-IDM’s existing NSG. Then point DNS to 4.154.241.58.

Option B: Provision a New Dedicated VM

If you prefer to keep NetBird isolated from other workloads:

Setting	Value
Resource Group	rg-netbird-prod (or your naming convention)
VM Name	vm-netbird-mgmt-01
Region	West US 3 (Phoenix, AZ)
Image	Ubuntu 24.04 LTS (Gen2)
Size	B2s (2 vCPU, 4 GiB RAM)
Authentication	SSH public key
OS Disk	30 GB Premium SSD
Public IP	Static SKU Standard
Additional cost	~$35-51/month

az group create --name rg-netbird-prod --location westus3

az vm create \
  --resource-group rg-netbird-prod \
  --name vm-netbird-mgmt-01 \
  --image Canonical:ubuntu-24_04-lts:server:latest \
  --size Standard_B2s \
  --admin-username azureadmin \
  --generate-ssh-keys \
  --public-ip-sku Standard \
  --public-ip-address-allocation Static \
  --os-disk-size-gb 30 \
  --storage-sku Premium_LRS

Note the public IP from the output — you need it for the DNS record.

1.2 Configure the NSG (Network Security Group)

Open these inbound ports on the VM’s NSG. NetBird consolidates Management, Signal, and Relay behind ports 80/443 via Traefik. Only UDP 3478 (STUN) is exposed directly.

Priority	Name	Port	Protocol	Source	Purpose
100	AllowHTTP	80	TCP	Any	Let’s Encrypt ACME challenge, HTTP-to-HTTPS redirect
110	AllowHTTPS	443	TCP	Any	Dashboard, Management API/gRPC, Signal gRPC, Relay WebSocket
120	AllowSTUN	3478	UDP	Any	STUN server for NAT traversal
200	AllowSSH	22	TCP	Your admin IPs	SSH management access

az network nsg rule create \
  --resource-group rg-netbird-prod \
  --nsg-name vm-netbird-mgmt-01NSG \
  --name AllowHTTP --priority 100 \
  --destination-port-ranges 80 --protocol Tcp --access Allow

az network nsg rule create \
  --resource-group rg-netbird-prod \
  --nsg-name vm-netbird-mgmt-01NSG \
  --name AllowHTTPS --priority 110 \
  --destination-port-ranges 443 --protocol Tcp --access Allow

az network nsg rule create \
  --resource-group rg-netbird-prod \
  --nsg-name vm-netbird-mgmt-01NSG \
  --name AllowSTUN --priority 120 \
  --destination-port-ranges 3478 --protocol Udp --access Allow

STUN/UDP is Required

UDP port 3478 cannot be proxied through HTTP reverse proxies. STUN uses raw UDP for NAT detection and must be directly reachable on the VM’s public IP.

1.3 Configure DNS

Create an A record with your DNS provider:

Type	Name	Value	TTL
A	netbird.gsisg.com	<VM Public IP>	300

Wait for DNS propagation before proceeding. Verify with:

dig +short netbird.gsisg.com

The output should match your VM’s public IP address.

1.4 Install Docker and Prerequisites

SSH into the VM and install Docker with the Compose plugin, plus jq and curl:

ssh azureadmin@netbird.gsisg.com

# Update system
sudo apt update && sudo apt upgrade -y

# Install prerequisites
sudo apt install -y ca-certificates curl gnupg jq

# Install Docker (official method)
sudo install -m 0755 -d /etc/apt/keyrings
curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
sudo chmod a+r /etc/apt/keyrings/docker.gpg

echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu \
  $(. /etc/os-release && echo "$VERSION_CODENAME") stable" | \
  sudo tee /etc/apt/sources.list.d/docker.list > /dev/null

sudo apt update
sudo apt install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin

# Add your user to the docker group (avoids needing sudo for docker commands)
sudo usermod -aG docker $USER

# Verify
docker --version
docker compose version

Log out and back in for the group change to take effect.

1.5 Deploy NetBird

Run the quickstart installation script. This downloads the latest stable release and generates all configuration files.

curl -fsSL https://github.com/netbirdio/netbird/releases/latest/download/getting-started.sh | bash

The script will prompt you for:

1. Domain name — enter netbird.gsisg.com
2. Reverse proxy selection — press Enter to accept the default [0] Traefik (recommended, includes auto-TLS via Let’s Encrypt)
3. NetBird Proxy service — enter N (not needed for our use case)

What the Script Creates

File	Purpose
docker-compose.yml	Defines Traefik, Dashboard, and NetBird Server containers
config.yaml	Combined server config (listen addresses, STUN, relay auth, embedded IdP, database)
dashboard.env	Dashboard environment (API endpoints, OAuth2/OIDC settings)

The script automatically starts all containers. Verify they are running:

docker compose ps

You should see three containers (netbird-traefik, netbird-dashboard, netbird-server) all in a running state.

Check logs for any errors:

docker compose logs --tail 50

1.6 Create the Admin Account

1. Open https://netbird.gsisg.com in your browser
2. You will be redirected to the /setup page (this page is only available when no users exist)
3. Create the admin account:
   • Email: your IT admin email
   • Name: your name
   • Password: a strong password (store in your password manager)
4. Click Create Account

Record These Credentials

The initial admin password is shown only during creation. Store it in a password manager immediately. This account serves as the break-glass local admin.

After creating the account, you are redirected to the login page. Sign in with the email and password you just created.

1.7 Record Critical Configuration Values

Before proceeding, locate and securely store these values from config.yaml:

# On the VM, display the encryption key
grep encryptionKey config.yaml

Value	Location	Why It Matters
server.store.encryptionKey	config.yaml	Encrypts setup keys and API tokens in the database. Losing this key means regenerating all setup keys and tokens.
server.authSecret	config.yaml	Shared secret for relay authentication
Admin email/password	Your password manager	Break-glass local admin access

Back Up the Encryption Key NOW

Store encryptionKey in a secure location (password manager, Azure Key Vault, or encrypted backup). If this key is lost, you cannot decrypt existing setup keys or API tokens. There is no recovery mechanism.

1.8 Enable Auto-Start on Reboot

The Docker Compose services are configured with restart: unless-stopped, so they will restart automatically after a VM reboot. Verify Docker itself starts on boot:

sudo systemctl enable docker

Verification

At this point you should have:

• Azure B2s VM running Ubuntu 24.04 in West US 3
• NSG rules allowing TCP 80, 443 and UDP 3478
• DNS record netbird.gsisg.com pointing to the VM’s static public IP
• Docker Compose running Traefik + Dashboard + NetBird Server
• Valid Let’s Encrypt TLS certificate (automatic via Traefik)
• Admin account created and login verified
• Encryption key backed up securely

Next Step

Proceed to Step 2: Entra ID Integration to connect Microsoft Entra ID for SSO authentication.
